Page 34
2-10
X8ST3-F/X8STE User's Manual
X8ST3-F/X8STE
2-5 Connectors/IO Ports
The I/O ports are color coded in conformance with the PC 99 specification. See the
figure below for the colors and locations of the various I/O ports.
Back Panel Connectors and IO Ports
Back Panel Connectors
1. Keyboard (Purple)
2. PS/2 Mouse (Green)
3. USB Port 0
4. USB Port 1
5. IPMI LAN (X8ST3-F)
6. COM 1
7. VGA
8. LAN1
9. LAN 2
1
2
3
4
5
6
7
8
9
