About the indicators on the display
SW LFE
L C R
SL S SR
; D ; PLII ; PL OPT DTS MEMORY ST
MONO D.RANGE COAX
1 2 3 4 5 6 8 7
qs qa 9 q;
Name Function
A SW
Lights up when the audio signal
is output from the SUB
WOOFER jack.
B LFE
Lights up when the disc being
played back contains an LFE
(Low Frequency Effect)
channel and the LFE channel
signal is actually being
reproduced.
C ; D
Lights up when the receiver is
decoding Dolby Digital signals.
Note
When playing a Dolby Digital
format disc, be sure that you
have made digital connections
and that INPUT MODE is set to
“AUTO” (page 43).
D ; PL/
; PLII
“; PL” lights up when the
receiver applies Pro Logic
processing to 2 channel signals
in order to output the center and
surround channel signals.
“; PLII” lights up when the
Pro Logic II Movie/Music
decoder is activated.
E OPT
Lights up when INPUT MODE
is set to “AUTO” and the source
signal is a digital signal being
input through the OPTICAL
jack.
Name Function
F DTS
Lights up when the receiver is
decoding DTS signals.
Note
When playing a DTS format
disc, be sure that you have made
digital connections and that
INPUT MODE is set to
“AUTO” (page 43).
G MEMORY
Lights up when a memory
function, such as Preset
Memory (page 41), etc., is
activated.
H Tuner
indicators
Lights up when using the
receiver to tune in radio stations
(page 39), etc.
I Preset
station
indicators
Lights up when using the
receiver to tune in preset radio
stations. For details on
presetting radio stations, see
page 41.
J D.RANGE Lights up when dynamic range
compression is activated (page
28).
K COAX Lights up when DVD/BD input
is selected. However,
“UNLOCK” appears on the
display if no digital signal is
input through the COAXIAL
jack.
