23
Playback
C
h
apt
er 2
P
la
y
ba
c
k
Playback Procedure
Note
When controlling this unit from an editing control unit connected to the
REMOTE connector on this unit, press the REMOTE button to turn it on. When
not, turn the button off.
1
Insert a cassette.
For details of cassette insertion see page 21, and for usable cassette types
see page 19.
The cassette is automatically drawn into the unit. The STOP button will
light, and a few seconds later a still image will appear on the monitor screen.
2
Press the PLAY button.
This starts the playback operation. When the tape is played back all the way
to the end, the unit automatically rewinds it and then stops.
2
1
dB 0
-12 -20
-30
-40
-60
dB 0
1 0 -1
-2
OVER
1
dB 0
-12 -20
-30
-40
-60
dB 0
1 0 -1
-2
OVER
2
dB 0
-12 -20
-30
-40
-60
dB 0
1 0 -1
-2
OVER
3
dB 0
-12 -20
-30
-40
-60
dB 0
1 0 -1
-2
OVER
4 PB FS 48k44.1k32k
REMOTE button
