Location and Function of Parts
Bluetooth headset
Headband
Left () unit
Left earpad
Right earpad
PAIRING button
VOL (volume) +*⁄– buttons
Indicator (blue)
Indicates the communication
status of the unit.
Indicator (red)
Indicates the power status of
the unit.
Jog switch
Controls various functions
when listening to music.
Multi function button
Controls various call
functions.
Right () unit
POWER button
Microphone
USB() jack
RESET button
* This button has a tactile dot.
