A
PPLICATION
E
XAMPLES
2-3
Network Aggregation Plan
With 24/48 parallel bridging ports (i.e., 24/48 distinct collision domains),
the Gigabit Ethernet Switch can collapse a complex network down into a
single efficient bridged node, increasing overall bandwidth and
throughput.
In the figure below, the 10/100/1000BASE-T ports on the Gigabit
Ethernet Switch are providing 1 Gbps connectivity for up to 24/48
segments through stackable switches. In addition, the switch is also
connecting several servers at 1 Gbps.
Figure 2-2. Network Aggregation Plan
10/100/1000 Mbps Segments
...
...
Server Farm
......
ES3526F
1
ES3526F
1
......
ES3526F
1
ES3526F
1
TigerSwitch 10/100/1000
8648T
RPU
