Mute” display, Modulation display, Pilot” display – Sennheiser SKP 500 User Manual
Page 9: Display backlighting

9
“MUTE” display
The “MUTE” display
ቨ
appears on the display panel when
the plug-on transmitter is muted (see “Muting the plug-on
transmitter” on page 12).
Modulation display
The level display for audio signal “AF”
ቩ
shows the
modulation of the plug-on transmitter.
When the audio input level is excessively high, the level
display for audio signal “AF”
ቩ
shows full deflection for the
duration of the overmodulation.
“PILOT” display
The “PILOT” display
ቧ
appears on the display panel when
the pilot tone transmission is activated (see “Activating/
deactivating the pilot tone transmission” on page 22).
Display backlighting
After pressing a button, the display remains backlit for
approx. 15 seconds.
ቨ
ቩ
ቧ
