Smooth Fitness 5.65I User Manual
Page 12
12
5.65i TREADMILL
ASSEMBLY
Step2: Assemble the console to the console masts
1).Rotate the console towards the direction of the arrow.
Caution: Do not Pinch the wire between the upright frame and the
console assembly( wires on right side)
2). Secure the console assembly to the uprights with 2 x
M8*20mm knobs
4). TIGHTEN ALL BOLTS NOW. Do not proceed until all bolts have
been fully tightened.
Caution Pinch point! Do not pinch wires between the frame.
Tighten all bolts and fasteners now
