ENFORCER E-37EV Alarm Pager System
SECO-LARM U.S.A., Inc. 3 SECO-LARM U.S.A., Inc.
33 3
Transmitter Installation
1. Mark locations for drilling the mounting bracket holes. Be careful that the area to be drilled
is free from wiring, trim, and/or any other obstructions.
2. Drill holes at the location marks. Position the transmitter where it will be mounted, but do
not secure immediately.
3. The transmitter should be permanently mounted only after all connections and tests
are made.
NOTES:
 Do not mount the E-37EV transmitter in the engine compartment as this automatically voids
the warranty.
 Do not power up the transmitter before the antenna connections are made as this may
damage the transmitter.
 In a building, mount as close to a window as possible.
 In a vehicle, mount under the dashboard or in the glove compartment.
Antenna Installation (see Connection Diagram on pg. 5)
The E-37EV can be connected to one of four types of antennas:
TYPE 1: Strip antenna (A Position)
1. E-37ANT (optional) can be used in either a building or vehicle.
2. Connect the male antenna plug into the transmitter jack marked “ANT.”
3. Place the antenna selection switch in the “A” position.
4. Do not secure the strip antenna to metal, window defrosters, or existing antennas.
Installation
Tr
an
sm
itt
er
Number of codes Over 2 million (factory pre-set)
Power 12VDC
RF output power 4W max.
Current drain
Standby 10mA
Active 1A
Frequency 27MHz
Antenna impedance 50 Ω
Range Up to 1 /
2
mile in open air 1
Dimensions 4 1 /
8
”x3 1 /
8
”x1 5 /
16
” (105x79x33 mm)
Weight 5.1-oz (145g)
1 Actual range may vary depending on the environment, installation, and/or antenna.
Rece
ive
r
Number of codes Learns up to 3 transmitter codes
Power 3VDC (2 AAA batteries) 2
Battery life Approx. 1 month 3
Current drain
Standby 1mA
Active (Beep) 20mA
Active (Vibrate) 50mA
Dimensions 3”x2 1 /
8
”x 5 /
8
” (76x54x16 mm)
Weight 1.6-oz (45g) (without battery)
2 Batteries not included
3 Based on 5 transmissions/day
Specifications
