LCD PANEL PRINTER CONFIGURATION
The LCD Panel is used by the operator in conjunction with the LINE and FEED
switches to manually enter printer configuration settings. Many of these settings can
also be controlled via software commands and in the case of conflict between
software and control panel settings, the printer will always use the last valid setting.
If you load a label job that includes software settings and then enter a new setting via
the LCD panel, the manually set values will be used by the printer. If you set the
values manually and then download a job with software settings, the software
settings will be used.
There are nine modes of operation. To enter the desired mode, the KEY SEQUENCE
combination listed in the table below must be performed. The initial LCD display
message is shown for each mode.
SATO CL Series “e” Printers
PN 9001074 Rev. B
Page 3-9
Section 3. Configuration
MODE
KEY SEQUENCE
INITIAL DISPLAY
PAGE
Normal
POWER
ONLINE
QTY:000000
3-10
Advanced
LINE + POWER
ADVANCED MODE
3-12
Test Print
FEED + POWER
TEST PRINT MODE
CONFIGURATION
3-22
Default Setting
LINE + FEED + POWER
DEFAULT SETTING
YES
NO
3-23
Clear Non-Standard Protocol
DSW2-7 ON + LINE + FEED
+ POWER
ALT. PROTOCOL
3-24
Protocol Code Download
DSW2-7 ON + POWER
USER DOWNLOAD
3-24
Hex Dump
DSW2-4 ON + POWER
ONLINE
QTY:000000
3-25
