SATO CL408e User Manual
Page 15
PHYSICAL
Page 1-6
PN 9001074 Rev. B
SATO CL Series “e” Printers
Section 1. Printer Overview
SPECIFICATION
CL408e
CL412e
CL608e
CL612e
DIMENSIONS
Wide
10.7 in. (271 mm)
13.8 in. (352 mm)
Deep
16.9 in. (430 mm)
16.9 in. (429 mm)
High
12.6 in. (321 mm)
11.7 in. (298 mm)
WEIGHT
28.7 lbs (13 Kg)
41.9 lbs (19 Kg)
POWER REQUIREMENTS
Voltage
110 V (
±
10 %)
220V (
±
10 %)
50/60 Hz (
±
1%)
Power Consumption
50W Idle
130W Operating
50W Idle
210W Operating
ENVIRONMENTAL
Operating Temperature
41° to 104°F (5° to 40°C)
Storage Temperature
-0° to 104°F (-20° to 40°C)
Operating Humidity
15-85 % RH, non-condensing
Storage Humidity
Max 90% RH, non-condensing
Electrostatic Discharge
8KV
REGULATORY APPROVALS
Safety
UL, CSA
RFI/EMI
FCC Class A
All specifications subject to change without notice.
