Sanyo VCC-6570P User Manual
Page 2
Depending on the conditions of use, installation and environment,
please be sure to make the appropriate settings and adjustments. If you
need help with installation and/or settings, please consult your dealer.
CONTENTS
PRECAUTIONS........................................................................................ 2
PARTS NAMES........................................................................................ 3
CONCERNING AUTO-IRIS LENSES ......................................................... 6
MOUNTING THE LENS ........................................................................... 7
CONNECTIONS ....................................................................................... 9
SETTINGS................................................................................................11
TROUBLESHOOTING..............................................................................16
SPECIFICATIONS.....................................................................................17
ACCESSORIES
1 Lens iris plug (4-pin)..................................................................1 pc.
2
Clamping core A .......................................................................1 pc.
3
Clamping core B .......................................................................2 pc.
4
Clamping core C .......................................................................1 pc.
1
2
3
4
FEATURES
•
Built-in interline transfer method 1/3" CCD, approx. 470,000
picture elements
•
Equipped with a DSP (Digital Signal Processor) function
•
Horizontal resolution, more than 520 TV lines
•
High sensitivity, minimum required illumination is 1.0 lux (F1.2)
•
Two types of backlight compensation functions (multi-spot
photometry and center focus photometry)
•
Low smear, anti-blooming, low lag, no burning and no geometric
distortion using the CCD solid state image device.
•
100% solid state components giving excellent immunity to shock
and vibration
•
Not subject to interference from magnetic or electrostatic fields
•
Power supply: 220 – 230 V AC operation
L53T5/XE GB 2001,
7,
26
English
1
