Specifications
Product type
Model
Video system
Display method
LCD panel
Lens
Projection lamp
Contrast ratio
Video input signal
S-video input signal
Component input signal
Horizontal resolution
Audio output
Computer RGB input signal
Pixel clock
Vertical frequency
Horizontal frequency
Computer control signal
Speaker system
Rated voltage
Input current
Rated frequency
Power consumption
Operating temperature
Storage temperature
Cabinet
I/R carrier frequency
Dimensions (approx.)
Weight (approx.)
Supplied accessories
Replacement parts
LCD Projector
XV-Z7000U
PAL/PAL 60/PAL-M/PAL-N/SECAM/NTSC 3.58/NTSC 4.43/DTV 480P/DTV 720P/DTV 1080I
LCD panel
ן 3, RGB optical shutter method
Panel size: 0.9 Љ (13.9 [H] ן 18.5 [W] mm)
Display method: Translucent TN liquid crystal panel
Drive method: TFT (Thin Film Transistor) Active Matrix panel
No. of dots: 480,000 dots (800 [H]
ן 600 [V])
1–1.2
ן zoom lens, F2.3–2.6, f ס 36.0–43.2 mm
DC 150 W lamp
350:1
RCA Connector: VIDEO, composite video, 1.0 Vp-p, sync negative, 75
Ω terminated
RCA Connector: AUDIO, 0.5 Vrms more than 22 k Ω (stereo)
4-pin Mini DIN connector
Y (luminance signal): 1.0 Vp-p, sync negative, 75
Ω terminated
C (chrominance signal): Burst 0.286 Vp-p, 75 Ω terminated
RCA Connector (INPUT 1 terminals)
Y: 1.0 Vp-p, sync negative, 75
Ω terminated
P B : 0.7 Vp-p, 75
Ω terminated
P R : 0.7 Vp-p, 75 Ω terminated
520 TV lines (DTV 720P input)
1.0 W (monaural)
15-
PIN MINI D- SUB CONNECTOR (INPUT 2 port):
RGB separate/composite sync/sync on green type analog input: 0–0.7 Vp-p, positive,
75
Ω terminated
S TEREO M INIJACK : AUDIO, 0.5 Vrms, more than 22 k Ω (stereo)
H ORIZONTAL SYNC . SIGNAL : TTL level (positive/negative) or composite sync (Apple only)
V ERTICAL SYNC . SIGNAL : Same as above
12–108 MHz
43–85 Hz
15–80 kHz
9-pin Mini DIN female connector (RS-232C port)
1
7 ⁄
64
Љ (2.8 cm) round
AC 100–240 V
2.6 A
50/60 Hz
230 W (Selecting “OFF” in the “Theater Mode”.)
200 W (Selecting “ON” in the ”Theater Mode”.)
41°F to 95°F (
ם5°C to ם35°C)
מ4°F to 140°F (מ20°C to ם60°C)
Plastic
38 kHz
10
15 ⁄
64
Љ (W) ן 2 29 ⁄
32
Љ (H) ן 8 5 ⁄
32
Љ (D) (260 ן 74 ן 207 mm) (main body only)
10 15 ⁄
64
Љ (W) ן 3 15 ⁄
64
Љ (H) ן 8 5 ⁄
32
Љ (D) (260 ן 82 ן 207 mm) (including
adjustment feet and projecting parts)
5.73 lbs. (2.6 kg)
Remote control, Two AAA size batteries, Rubber leg tips for remote control, Power cord
(11
Ј 10Љ, 3.6 m), DIN-D-sub RS-232C cable (6 45 ⁄
64
Љ, 15 cm), Extra air filter, Lens cap
(attached), Lens cap strap, LCD projector operation manual
Lamp unit (Lamp/cage module) (BQC-PGC20X//1), Remote control (RRMCG1636CESA),
AAA size batteries, Rubber leg tips for remote control (GLEGG9095CEZZ), Power cord
(CACCU5013DE01), DIN-D-sub RS-232C cable (QCNW-5288CEZZ), Air filter
(PFILD0123CEZZ), Lens cap (PCOVZ1095CEKA), Lens cap strap (UBNDT0013CEZZ),
LCD projector operation manual (TINS-7273CEZZ)
This unit has some inactive TFTs within acceptable tolerances which
may result in illuminated or inactive dots on the picture screen. This
will not affect the picture quality or the life expectancy of the unit.
If you have any questions about this matter, please call toll free 1-877-
DTV-SHARP (1-877-388-7427).
U.S.A. ONLY
This SHARP projector uses LCD (Liquid Crystal Display) panels. These
very sophisticated panels contain 480,000 pixels (
ן RGB) TFTs (Thin
Film Transistors). As with any high technology electronic equipment
such as large screen TVs, video systems and video cameras, there
are certain acceptable tolerances that the equipment must conform
to.
Specifications are subject to change without notice.
