315 XPB12 HEX BOLT 5 ⁄
16
"-18 X 1 1 ⁄
4
"
316 X1672316 TABLE BRACKET
317 X1672317 TABLE LOCKING KNOB
318 X1672318 UPPER BRACKET
319 X1672319 BEARING BRACKET
320 XP6200 BEARING 6200Z
321 XPRO1M RETAINING RING 10MM
322 X1672322 BLADE GUIDE BODY
323 X1672323 GUIDE BLOCK
324 XPRP44M ROLL PIN 3 X 10
325 X1672325 TABLE INSERT
326 X1672326 GAUGE
329 X1672329 INDICATOR
330 XPS18 PHLPHD SCREW 10-24 X 1 ⁄
4
"
331 X1672331 LOWER BRACKET
332 X1672332 MITER GAUGE
467 XPCB12 CARRIAGE BOLT 3 ⁄
8
"-16 X 2"
486 X1672486 SLEEVE M6 X 15
487 X1672487 GUIDE RAIL
488 XPSB07M CAP SCREW M6-1 X 30
489 X1672489 GUIDE RAIL CAP
490 X1672490 FENCE HEADSTOCK
491 X1672491 KNOB
494 XPN08 HEX NUT 3 ⁄
8
"-16
495 X1672495 DO NOT OPEN COVER LABEL
496 X1672496 W1672 ID/WARNING LABEL
497 X1672497 WEAR SAFETY GLASSES LABEL
498 X1672498 CAUTION ELECTRICITY LABEL
REF PART # DESCRIPTION
159 X1672159 ADAPTER
162 XPSS11 SETSCREW 1 ⁄
4
"-20 X 1 ⁄
4
"
163 X1672163 IDLER PULLEY
164 XPVA31 V-BELT A-31
201 XPCB11 CARRIAGE BOLT 5 ⁄
16
"-18 X 1"
202 XPW02 FLAT WASHER 3 ⁄
8
"
203 XPLN03 LOCK NUT 5 ⁄
16
"-18
206 X1672206 KNOB
207 X1672207 GUARD
211 XPK34M KEY 5 X 5 X 20
213 X1672213 MOTOR PULLEY
214 X1672214 MOTOR
215 XPLW01 LOCK WASHER 5 ⁄
16
"
222 X1672222 STAND
301 X1672301 GUIDE BAR
302 XPB19 HEX BOLT 1 ⁄
4
"-20 X 1 ⁄
2
"
303 XPB05 HEX BOLT 1 ⁄
4
"-20 X 3 ⁄
4
"
304 X1672304 BLADE COVER
305 XPTS002 THUMB SCREW 1 ⁄
4
"-20 X 1 ⁄
2
"
306 XPW06 FLAT WASHER 1 ⁄
4
"
307 XPB51 HEX BOLT 1 ⁄
4
"-20 X 3 ⁄
8
"
308 X1672308 TABLE
309 X1672309 TABLE PIN
310 XPB66 HEX BOLT 3 ⁄
8
"-16 X 2 1 ⁄
4
"
311 X1672311 TRUNNION CLAMP
312 X1672312 TRUNNION
313 XPTS006 THUMB SCREW 1 ⁄
4
"-20 X 3 ⁄
4
"
314 X1672314 CPTD HXSCREW 1 ⁄
4
"-20 X 5 ⁄
8
"
