Woodstock W1672 - Manual (Page 42)

41
101 XPB03 HEX BOLT 5 ⁄
16
"-18 X1"
102 XPW07 FLAT WASHER 5 ⁄
16
"
103 X1672103 SPRING
104 X1672104 BRACKET
105 X1672105 BAR SETTING PLATE
107 X1672107 SPECIAL WASHER
108 X1672108 BODY
109 X1672109 SPECIAL NUT
110 X1672110 SPRING
111 X1672111 QUICK-HANDLE LEVER
112 XPRP49M ROLL PIN 5 X 25
113 X1672113 TENSION BOLT
114 X1672114 GUIDE ROD
115 XPR39M EXT RETAINING RING 8MM
116 X1672116 UPPER WHEEL BASE
117 X1672117 UPPER WHEEL SHAFT
118 X1672118 UPPER WHEEL
119 XPR21M INT RETAINER RING 35MM
120 XP6202 BEARING 6202ZZ
122 X1672122 RUBBER TIRE
123 X1672123 SHOPFOX PLAQUE
125 X1672125 UPPER WHEEL GUARD
126 X1672126 HINGE
127 X1672127A
SWITCH
127A X1672127B SWITCH PLATE
127B X1672127C SWITCH KEY
128 XPS01 PHLPHD SCREW 10-24 X 1 ⁄
2
"
129 X1672129 TRACKING KNOB
REF PART # DESCRIPTION
130 XPN02 HEX NUT 5 ⁄
16
"-18
131 XPN06 HEX NUT 1 ⁄
2
"-12
132 XPLW07 LOCK WASHER 1 ⁄
2
"
133 XPLW02 LOCK WASHER 1 ⁄
4
"
134 XPSB17 CAP SCREW 1 ⁄
4
"-20 X 3 ⁄
8
"
135 XP6004 BEARING 6004ZZ
136 XPK12M KEY 5 X 5 X 30MM
137 X1672137 SHAFT
138 X1672138 DRIVE WHEEL
139 X1672139 LEFT HANDED NUT 3 ⁄
4
"-16
140 X1672140 LOWER WHEEL GUARD
141 XPB35 HEX BOLT 3 ⁄
8
"-16 X 2 1 ⁄
2
"
142 XPN08 HEX NUT 3 ⁄
8
"-16
143 XPB09 HEX BOLT 5 ⁄
16
"-18" X 1 ⁄
2
"
144 XPLW01 LOCK WASHER 5 ⁄
16
"
145 X1672145 PIN 6 X 16
146 X1672146 GUARD LOCKING KNOB
147 X1672147 SPECIAL SCREW
148 X1672148 STRAIN RELIEF
149 X1672149 KNOB
150 XPWRCRD110V 110V LONG POWER CORD
151 XPWRCRDRECP POWER CORD W/RECP
152 XPWRCRDPLUG POWER CORD W/PLUG
153 XPLW03 FLAT WASHER 3 ⁄
16
"
155 XPB11 HEX BOLT 5 ⁄
16
"-18 X 1 1 ⁄
2
"
156 X1672156 ADJUSTING SCREW
157 XPN04 HEX NUT 5 ⁄
8
"-11
158 X1672158 BEARING HOUSING
REF PART # DESCRIPTION
