EN-34
1. Turn off the projector and unplug the AC power
cord.
2. Place a protective sheet (cloth) beneath the
projector. Turn the projector over so you can
access the lamp cover.
3. Loosen the access panel screw and open the
panel.
4. Loosen the screws on the bottom of the lamp
assembly.
5. Grasp the lamp handle and pull the lamp
assembly directly out of the projector.
6. Replace with the new lamp.
7. Tighten the screws on the bottom of lamp
assembly.
8. Tighten the screw on the lamp cover.
9. Reset the lamp hour. Refer to the “Setting
(Computer/Video Mode)” menu.
Dispose of the used lamp according to local regulations.
Ensure that screws are tightened properly. Screws not tightened fully may result
in injury or accidents.
Since the lamp is made of glass, do not drop the unit and do not scratch the
glass.
Do not reuse the old lamp. This could cause the lamp to explode.
Be sure to turn off the projector and unplug the AC power cord before replacing
the lamp.
Do not use the projector with the lamp cover removed.
ORDER REPLACEMENT LAMP
Replacement lamp can be ordered through your dealer. When ordering a projection
lamp,give the following information to the dealer.
Model No. of your projector: PLC-WXU10N/ WXU10E/ WXU10B
Replacement Lamp Type No.: POA-LMP113
(Service Parts No. 610 336 0362)
