37
CONNECTING WITH EXTERNAL DEVICES (Continued)
Outputting video and audio (video output)
You can output video and audio data from the TV set through the AV output terminals (AV-OUT).
Note:
■
AV2 has 2 OUT modes (see page 24).
■
When using the S-Video input for AV-IN1, no video output will be made to the AV output terminal, but audio
output will be made for connection to external audio systems.
Notes:
Connect a VCR,
Audio amplifier,
etc.
How to fix the cables
• Fix cables and cords with the attached cable clamps
so that they do not get caught when mounting the
cover.
• Connect the cables and cords after fixing the cable
clamps (2 positions).
VO
L
CH
ME
NU
TV
/VID
EO
MA
IN P
OW
ER
Cable clamps
VO
L
CH
ME
NU
TV
/VID
EO
MA
IN P
OW
ER
VIDEO
AUDIO
L
Y
P
B
P
R
R
AUDIO
L
R
COMPONENT
AV-IN2/OUT
