Chapter 2 Performance Tests
58502A Operational Verification
2-8
User’s Guide
Figure 2-4. ALARM/STATUS Port
If the Alarm indicator illuminates and output pins 2, 3, and 4 go low,
then all associated ALARM/STATUS output circuitry is functional.
4
Mark Pass or Fail in Line 2 on the Operational Verification portion of
the 58502A Performance Test Record, located on page 2-14.
This completes the operational verification.
1
2
3
4
5
6
7
8
9
GND
Outputs
GND
GND
