Model W1798 Professional Spray Gun
-14-
PARTS
REF PART�# DESCRIPTION REF PART�# DESCRIPTION
1 X1798001 PAINT�INLET�JOINT 11 X1798011 COMPRESSION�SPRING
2 X1798002 DIRECTIONAL�SCREW 12 X1798012 O-RING
3 X1798003 SEALING�RING 13 X1798013 AIR�INLET�PLUG
4 X1798004 NOZZLE�ASSEMBLY 14 X1798014 FLUID�ADJUSTMENT�KNOB
5 X1798005 FLUID�NOZZLE 15 X1798015 COMPRESSION�SPRING
6 X1798006 PATTERN�ADJUSTMENT�VALVE 16 X1798016 FLUID�NEEDLE�ASSEMBLY
7 X1798007 TRIGGER�PIN 17 X1798017 RESERVOIR
8 X1798008 TRIGGER 18 X1798018 GUN�BODY
9 X1798009 O-RING 19 X1798019 COVER�ASSEMBLY
10 X1798010 AIR�VALVE�SEAT 20 X1798020 REBUILD�KIT
