Sinclair Surface Prep Machine 390 User Manual
Page 9
9
HANDLE
Schematic #
Part #
Description
1 015439
Screw
2 & 11
014193
Front & Rear Pistol Stock
3
015440
Adjusting Lever for Shaft
4
05441
Lever for Right Switch
5 014814
Screw
Nut
6
015442
Lever for Water Supply
7 015443
Splint-Pin
8 015444
Spacer
9
015445
Lever for Left Switch
10 015446
Ball
10.1 018611
Spacer
12 015447
Washer
13
015448
Screw for Handle Housing
14
015450
Screw for Handle
15
015450
Screw for Cover
16 015451
Screw
Nut
17 014194
Safety
Switch
18 015452
Spring
19 015453
Screw
20
021641
Rod for Handle
21
015455
Pull Rod for Shaft Adjustment
22
014731
Locking Screw for Joint
23 015457
Screw
Nut
24 021639
Joint
26
021638
Attachment for Joint
27 014831
Shim
28 015461
Spring
29 015462
Retention
Pin
30 016922
Gear
Rim
31 021642
Pivot
Bracket
34 015467
Pin
35
015468
Screw for Retention Pin
36
032678
Handle, Complete #1-35
37
032680
Grip, Complete #1-18
38
032681
Joint, Complete #22-24; 26-28
