Sinclair Surface Prep Machine 390 User Manual
Page 8
8
7.0 Schematics
MACHINE
Schematic #
Part #
Description
1
021625
Top Cover + Motor Housing
2 021626
Base
Link
3 021627
Rubber
Washer
4
021629
Fastening Screw for Gear
5 021628
Balancing
Weight
6
021629
Fastening Screw for Weight
7
021630
Fastening Screw for Housing
8
017284
Screw 4.8 x 13
9 017283
Axle
Retainer
10 021631
Wheel
Axle
11 018080
Washer
12 016928
Transport
Wheel
13 014849
Circlip
Ring
14 014830
Washer
15 021633
Wheel
Cover
16 014761
Screw
17
015478
Screw Nut for Fan Wheel
18 015481
Washer
19 015480
Fan
Wheel
20
015481
Screw M4 x 12
22 015483
Centifugal
Switch
23 018417
Isolation
Ring
24
018412
Stator 53 (110V/60Hz)
25 015485
Isolation
Paper
26 015487
Shim
28 015486
Bearing
6002
29 015488
Rotor
(110V/60Hz)
30
015489
Bearing E 20
31 015485
Isolation
Paper
32 033964
Complete
Gear
33 021634
Drive
Hub
34 021635
Spacer
35
015401
Drive Hub Plate
36
014760
Screw for Hub M8 x 20
