Sinclair Surface Prep Machine 390 - Manual (Page 11)

11
GEAR
Schematic # Part # Description
31 015507 Oil Seal Washer
32 033963 Top Cover
33 018422 O-Ring
34 018237 Washer
35 015489 Bearing E20
36 018424 Lay Shaft
37 018425 Bearing 16-004
38 018426 Bearing E15
39 015508 Gear Shaft
40 015509 Gear
41 018427 Gear Holder
42 018428 Bearing 16.001
43 018429 Planetary Box
44 015510 Oil Seal Washer
45 015511 Washer
46 018219 Grup Screw M4 x 10
