General
PowerSaver
Preset Timing
Modes
General
Model Name SyncMaster 173B
LCD Panel
Size 17.0 inch diagonal
Display area 337.92 (H) x 270.336 (V)
Pixel Pitch 0.264 (H) x 0.264 (V)
Type a-si TFT active matrix
Viewing Angle 140/120(H/V)
Synchronization
Horizontal 31 ~ 81 kHz
Vertical 56 ~ 75 Hz
Display Color
16,194,277 colors
Resolution
Optimum resolution 1280 x 1024@60Hz
Maximum resolution 1280 x 1024@75Hz
Input Signal, Terminated
RGB Analog 0.7 Vpp positive at 75 ohms
Separate H/V sync, Composite, Sync-on-Green
TTL level positive or negative
Maximum Pixel Clock
135 MHz
Power Supply
AC 90 ~ 264 VAC rms, 60/50 Hz ± 3Hz
Signal Cable
15pin-to-15pin D-sub cable, detachable
Power Consumption
42W (Maximum)
Dimensions (WxDxH) / Weight
382.0 x 177.0 x 435.0 mm / 4.9kg
VESA Mounting Interface
75mm x 75mm (for use with Specialty(Arm) Mounting hardware.)
Environmental considerations
Operating Temperature: 50°F ~ 104°F(10°C ~ 40°C)
Humidity: 10% ~ 80%, non-condensing
Storage Temperature: -4°F ~113°F (-20°C ~ 45°C)
Humidity: 5% ~ 95%, non-condensing
Dot Acceptable
TFT LCD panel manufactured by using advanced semiconductor technology with precision of
99.999% above is used for this product. But the pixels of RED, GREEN, BLUE and WHITE color
seem to be bright sometimes or some of black pixels could be seen. This is not from bad quality
and you can use it without uneasiness.
