Samsung 152V User Manual
Page 50
General
PowerSaver
Preset Timing
Modes
General
Model Name
SyncMaster 192V
LCD Panel
Size
19.0 inch diagonal
Display area
404.6 (H) x 330.0 (V)
Pixel Pitch
0.294 (H) x 0.294 (V)
Type
a-si TFT active matrix
Viewing Angle
85/85/85/85(H/V)
Synchronization
Horizontal
31 ~ 81 kHz
Vertical
56 ~ 75 Hz
Display Color
16,294,277 colors
Resolution
Optimum resolution
1280 x 1024@60Hz
Maximum resolution
1280 x 1024@75Hz
Input Signal, Terminated
RGB Analog 0.7 Vpp positive at 75 ohms
Separate H/V sync, Composite,
TTL level positive or negative
Maximum Pixel Clock
135 MHz
Power Supply
AC 90 ~ 264 VAC rms, 60/50 Hz ± 3Hz
Signal Cable
15pin-to-15pin D-sub cable, detachable
Power Consumption
45W (Maximum)
Dimensions (WxDxH)
428.0 x 59.5 x 356.0 mm (Without Stand)
428.0 x 204.0 x 433.0 mm (After folding the Stand)
Weight
6.7kg (With Basic Stand)
VESA Mounting Interface
100mm x 100mm (for use with Specialty(Arm) Mounting hardware.)
Environmental considerations
Operating
Temperature: 50°F ~ 104°F(10°C ~ 40°C)
Humidity: 10% ~ 80%, non-condensing
Storage
Temperature: -4°F ~113°F (-20°C ~ 45°C)
Humidity: 5% ~ 95%, non-condensing
Dot Acceptable
