LOCATION OF THE BUTTONS
Control panel
1 (standby/on/attenuator) button
2 +/– buttons
3 LOUD (loudness) button
4 SEL (select) button
5 DISP (display) button
6 Cassette compartment
7 AM button
8
0 (eject) button
9 TAPE 23 button
p FM button
q
¢
/
4
buttons
• Also functions as SSM buttons when pressed
together.
w MO (monaural) button
e RPT (repeat) button
r Number buttons
t MODE button
y SCM (sound control memory) button
u
(control panel release) button
Display window
MODE SCM
MO RPT
1 2 3 4 5 6 9 p 8 q
y r
7
t u w e
i o
g d f h
a s ;
Display window
Display window
i FM band number indicators
FM1, FM2, FM3
o AM band indicator
; TAPE indicator
a Tuner reception indicators
MO (monaural), ST (stereo)
s RPT (repeat) indicator
d SCM (sound control memory) indicator
f Volume (or audio) level indicator
g Main display
h LOUD (loudness) indicator
