Rear Seat Heaters: Powered Seats
Rear Seat Heaters: Powered Seats
Fig. 12.9
DIMMER CONTROLLED LIGHTING
(CIRCUIT CONTINUED)
TIMER
LH REAR SEAT
HEATER TIMER
TIMER
RH REAR SEAT
HEATER TIMER
STATE
LOCATE
STATE
LOCATE
LH REAR SEAT
HEATER SWITCH
RH REAR SEAT
HEATER SWITCH
LH REAR SEAT CUSHION HEATER LH REAR SEAT SQUAB
HEATER
RH REAR SEAT CUSHION HEATER RH REAR SEAT SQUAB
HEATER
VARIANT: LWB / Powered Rear Seat Vehicles
VIN RANGE: All
DATE OF ISSUE: SEPTEMBER 1997
