XJ Series 1998
DATE OF ISSUE: SEPTEMBER 1997
Appendix
SCP Message Matrix
T = Transmit; R = Receive
# Message Name INST BPM DDCM PDCM DSCM PSCM DRDCM PRDCM SLCM
1 Vehicle speed T .............. R ............. R ..............................................................................................................
2 Brake pedal pressed T .............. R ....................................................................................................................... R .....
3 Module not programmed R ............. T .............. T .............. T .............. T ............. T .............. T ............. T .............. T .....
4 Left hand drive vehicle ............... T ............. R ..................................................................................................... R .....
5 Valet mode OFF ............... T ....................................................................................................................... R .....
6 Non-superlocking vehicle ............... T ............. R ..............................................................................................................
7 Trailer disconnected ............... R ....................................................................................................................... T .....
8 Right hand drive vehicle ............... T ............. R ..................................................................................................... R .....
9 Valet mode ON ............... T ....................................................................................................................... R .....
10 Superlocking ON ............... T ............. R ..............................................................................................................
11 Trailer connected ............... R ....................................................................................................................... T .....
12 Reverse gear selected T ................................................. R .................................................................................... R .....
13 Not-in-park switch – inactive ............... T ............. R ............. R ............. R .............................. R ........................................
14 Not-in-park switch – active ............... T ............. R ............. R ............. R .............................. R ........................................
15 Engine running T .............. R ................................................................................................................................
16 Charging OK T ......................................................................................................................................... R .....
17 Inertia switch – inactive ............... T ............. R ............. R .............................................................................................
18 Inertia switch – active ............... T ............. R ............. R .............................................................................................
19 Ignition switch status R ............. T ............. R ............. R ............. R ............. R ............. R ............. R .............. R .....
20 Key not-in-ignition ............... T ............. R ............. R ............. R ............. R ............. R ............................... R .....
21 Key in-ignition ............... T ............. R ............. R ............. R ............. R ............. R ............................... R .....
22 Seatbelt telltale OFF R ............. T ................................................................................................................................
23 Low washer fluid warning OFF R ............. T ................................................................................................................................
24 Seatbelt telltale ON R ............. T ................................................................................................................................
25 Low washer fluid warning ON R ............. T ................................................................................................................................
26 Security audible indication ............... R .............. T .............. T .................................................................................... T .....
27 Remote panic enabled ............... R ............. R ............. R .................................................................................... T .....
28 Intrusion sensing disabled ...................................................................................................................................................
29 Security disarm ............... R ............. R ............. R .................................................................................... T .....
30 Ignition key invalid ............... T ....................................................................................................................... R .....
31 Intrusion breach ............... T ....................................................................................................................... R .....
32 Intrusion self-check failure ............... T ....................................................................................................................... R .....
33 Intrusion sensing enabled ...................................................................................................................................................
34 Security armed ............... R ............. R ............. R .................................................................................... T .....
35 Ignition key valid ............... T ....................................................................................................................... R .....
36 Memory set chime ............... R .................................................................................... T ........................................
37 Recall memory 1 ............... R ............. R ............. R ............. R ............................... T ........................................
38 Recall memory 2 ............... R ............. R ............. R ............. R ............................... T ........................................
39 Recall memory 3 ............... R ............. R ............. R ............. R ............................... T ........................................
40 Set memory 1 ............... R ............. R ............. R ............. R ............................... T ........................................
41 Set memory 2 ............... R ............. R ............. R ............. R ............................... T ........................................
42 Set memory 3 ............... R ............. R ............. R ............. R ............................... T ........................................
43 Stop memory recall ............... R ............. R ............. R ............. R ............................... T ........................................
44 Memory LED OFF ................................ R .................................................................. T ........................................
45 Memory recall cancelled ............... T .............. T .............. T .............. T .............................. R ........................................
46 Memory LED ON ................................ R .................................................................. T ........................................
47 Mirror fold-flat ............... R .............. T ...............................................................................................................
48 Mirror fold-out ............... R .............. T ...............................................................................................................
49 Stop mirror ................................. T .............. R .............................................................................................
50 Driver mirror up ................................. T .............. R .............................................................................................
51 Passenger mirror up ................................. T .............. R .............................................................................................
52 Driver mirror down ................................. T .............. R .............................................................................................
53 Passenger mirror down ................................. T .............. R .............................................................................................
54 Passenger mirror right ................................. T .............. R .............................................................................................
