— 8 —
D
Connect Controller to VCR
Connect the Controller to the CABLE BOX Controller connector
on the rear panel.
E
Turn on cable box or DBS receiver
Select a channel other than channel 9 on your cable box, or
channels 100, 205 on your DBS receiver.
F
Access Main Menu screen, then Initial Set screen on VCR
Press MENU on the Remote. Press
rt
to move the highlight bar
(arrow) to “INITIAL SET”, then press OK or
e
.
G
Access Cable Box Set screen or DBS
Receiver Set screen
Press
rt
to move the highlight bar
(arrow) to “CABLE BOX SET” or “DBS
RECEIVER SET”, then press OK or
e
.
H
Select output channel
Your selection depends on how the unit is
connected to your VCR.
● If the unit is connected to your VCR’s
ANT. IN terminal on the rear panel,
Press
rt
until the channel number
representing the cable box’s output (CH2
– CH9) or DBS receiver’s output (CH3 or CH4) appears on the
screen.
● If the unit is connected to your VCR’s AUDIO/VIDEO IN
connectors on the front panel, press
rt
until “ON F-1
(FRONT)” appears on the screen.
● If the unit is connected to your VCR’s AUDIO/VIDEO IN
connectors on the rear panel, press
rt
until “ON L-1 (REAR)”
appears on the screen.
● If you do not use any unit, press
rt
until “OFF” appears on
the screen.
I
Access Brand Set screen
Press OK or e.
● If the Clock Set screen appears, perform “Manual Clock Set”. If
you press MENU after the clock has been set, the Brand Set
screen appears.
J
Enter brand code and perform test
Press the appropriate Number keys on the
Remote to enter the brand code from the
following list, then press OK or e.
For cable box
● If the cable box’s channel changes to 9,
setting is complete. Press OK.
● If the cable box’s channel does not
change to 9;
A
Press
rt
to move the highlight bar
(arrow) to “NO”, then press OK or e.
B
Repeat step
0
0
0
0
until the cable box’s channel changes to 9 by
entering another code.
C
If the channel does not change after going through all the code
numbers listed for your model of cable box, then try all the
other numbers.
For DBS receiver
● If the DBS receiver’s channel changes to
the channel listed below for your brand,
setting is complete. Press OK or e.
● If the DBS receiver’s channel does not
change as shown above;
A
Press
rt
to move the highlight bar (arrow) to “NO”, then
press OK or e.
B
Repeat step
0
0
0
0
.
CABLE BOX BRAND
CODE
ARCHER
CABLETENNA
CABLEVIEW
CITIZEN
CURTIS
DIAMOND
GC BRAND
GEMINI
GENERAL INSTRUMENTS
HAMLIN
JASCO
JERROLD
NOVAVISION
OAK
PANASONIC
PULSER
RCA
REGAL
REMBRANDT
SAMSUNG
SCIENTIFIC ATLANTA
SIGMA
SL MARX
SPRUCER
STARGATE
TELEVIEW
TOCOM
UNIKA
UNIVERSAL
VIDEOWAY
ZENITH
1, 5, 17
1, 17
15, 16, 17, 21, 25
15, 16, 17, 21, 25
2, 8
1, 17
15, 16, 17, 21, 25
15
1, 4, 6, 11, 12, 15, 28
10, 18, 23
15
1, 4, 6, 11, 12, 15, 28
2, 8
7, 20
13, 14
15, 16, 17, 21, 25
13, 14
10, 18, 23
1, 16, 17
5, 16, 24
2, 8
7, 20
5, 16, 17, 24, 25
13, 14
5, 15, 16, 17, 21, 24, 25
5, 16, 24
1, 4, 16
1, 17
16, 17, 25
3, 9, 22
3, 9, 22
DBS RECEIVER BRAND
CODE
DBS RECEIVER BRAND
CODE
JVC (DISH Network)
ECHOSTAR (DISH
Network)
51
51
SONY (DSS)
RCA (DSS)
41
40
JVC
ECHOSTAR
]
]
100
100
SONY
RCA
]
]
205
205
