User’s Manual 333
Serial Port B Address Register SBAR 0x00D1 W xxxxxxxx
Serial Port B Long Stop Register SBLR 0x00D2 W xxxxxxxx
Serial Port B Status Register SBSR 0x00D3 R 0xx00000
Serial Port B Control Register SBCR 0x00D4 W xx000000
Serial Port B Extended Register SBER 0x00D5 W 00000000
Serial Port C Data Register SCDR 0x00E0 R/W xxxxxxxx
Serial Port C Address Register SCAR 0x00E1 W xxxxxxxx
Serial Port C Long Stop Register SCLR 0x00E2 W xxxxxxxx
Serial Port C Status Register SCSR 0x00E3 R 0xx00000
Serial Port C Control Register SCCR 0x00E4 W xx000000
Serial Port C Extended Register SCER 0x00E5 W 00000000
Serial Port D Data Register SDDR 0x00F0 R/W xxxxxxxx
Serial Port D Address Register SDAR 0x00F1 W xxxxxxxx
Serial Port D Long Stop Register SDLR 0x00F2 W xxxxxxxx
Serial Port D Status Register SDSR 0x00F3 R 0xx00000
Serial Port D Control Register SDCR 0x00F4 W xx000000
Serial Port D Extended Register SDER 0x00F5 W 00000000
Serial Port E Data Register SEDR 0x00C8 R/W xxxxxxxx
Serial Port E Address Register SEAR 0x00C9 W xxxxxxxx
Serial Port E Long Stop Register SELR 0x00CA W xxxxxxxx
Serial Port E Status Register SESR 0x00CB R 0xx00000
Serial Port E Control Register SECR 0x00CC W xx000000
Serial Port E Extended Register SEER 0x00CD W 00000000
Serial Port F Data Register SFDR 0x00D8 R/W xxxxxxxx
Serial Port F Address Register SFAR 0x00D9 W xxxxxxxx
Serial Port F Long Stop Register SFLR 0x00DA W xxxxxxxx
Serial Port F Status Register SFSR 0x00DB R 0xx00000
Serial Port F Control Register SFCR 0x00DC W xx000000
Serial Port F Extended Register SFER 0x00DD W 00000000
Table D-1. Rabbit 3000A Internal I/O Registers (continued)
Register Name Mnemonic I/O Address R/W Reset
