Figure B-9. Short Chip Select Timing: 8 kHz, Read Operation
Figure B-10. Short Chip Select Timing: 16 kHz, Read Operation
32 kHz
ADD R
DAT A
T1
T2
Valid
/O Ex
/CSx
clock
8 kHz ope ratio n
32 kHz
ADD R
DAT A
T1
T2
Valid
/O Ex
/CSx
clock
16 kHz ope ratio n
