Jensen VM9512 - Manual (Page 11)

7
VM9512
CONTROLS AND INDICATORS
Button Operation
1. OPEN/CLOSE
Press to activate the automatic mechanical system and
move the TFT monitor into viewing position. Press again to
close the TFT.
2. DISP
With the TFT monitor open, press to cycle through
information available on the TFT screen.
With the TFT monitor closed, press and hold to view the
clock.
In DVD Mode, press to view the top and bottom information
bars. Press again to turn “Display Off”.
3. AS
Press to automatically store the first six strong stations in
preset memory. Applies to current band only.
4. BAND
Press the BAND button to change the AM, FM or SAT
band.
5. AUDIO
Rotate to adjust the volume. Press to enter and/or confirm
audio settings.
6. SRC
Press to select playing mode.
7. LCD Display
8. MUTE
Press to silence the receiver. Press again to resume previous
volume level.
BT Mode: Answer Bluetooth call.
NOTE: The VM9512 features Softmute, which will allow
the volume to increase or decrease gradually when the
MUTE function is activated or deactivated.
9. IR Remote Control Receiver
10. (left joystick)
DVD/Disc Mode: Press once to play back the previous
chapter/track.
TUNER Mode: Press once to auto-search for the previous
available radio station.
MENU Mode: Press once to move the cursor to the left.
11. (down joystick)
DVD/Disc Mode: Press once for slow forward/slow reverse.
TUNER Mode: Press to go down one frequency step.
MENU Mode: Press once to move the cursor down.
12. Reset
Press to reset system settings to factory default (except the
password and parental lock setting).
15
14
13
20
16
8 6 19 9
s Audio Enter
5
Pres
12 10 11
BAND AS DISP OPEN
7 1 2 4 3
VM9512
18 21
