ENGINE

John Deere Model 4045T – 4.5 liter, 90 SAE net hp turbo-

●

charged, isolation mounted

Vertical spin-on engine oil filter

●

Spin-on John Deere fuel filter with water separator

●

Oil-to-water engine oil cooler

●

Antifreeze, –34°F (–37°C)

●

Coolant recovery tank

●

Serpentine belt with automatic belt tensioner

●

Sucker-type cooling fan

●

Enclosed safety fan guard

●

High ambient temperature engine cooling

■

Dual element dry-type air cleaner

●

Muffler, underhood with curved-end exhaust stack

●

Chrome exhaust extension

■

Electric ether starting aid

■

Engine coolant heater, 1,000 watts

■

POWER TRAIN

Powershift transmission

■

Torque converter with electrically actuated twist grip

F-N-R in 1st through 4th gears

Transmission with powershift reverser and torque

●

converter
Fully synchronized four forward, four reverse speeds /

Isolation mounted to mainframe

Transmission oil cooler

●

Vertical spin-on transmission filter

●

Electric forward-neutral-reverse control lever with neutral

●

safety switch interlock

Electric clutch cutoff on gearshift and loader levers

●

Differential lock, electric foot-actuated

●

Planetary final drives

●

Hydraulic service brakes

●

Inboard, wet multi-disc, self adjusting and self equal-

izing / Conform to SAE J1473

Parking/emergency brake with electric switch control

●

Spring applied, hydraulically released wet multi-disc /

Independent of service brakes / Conforms to SAE J1473

Hydrostatic power steering with emergency manual mode

●

Non-powered front axle

●

Mechanical-front-wheel-drive with limited slip differential

■

Electric on/off control / Drive-shaft guard / Sealed axle

Tires

11L-16 F3 front tires

●

14.5/75-16.1 F3 front tires

■

12.5/80-18 traction front tires

■

19.5L-24 R4 rear tires

●

21L-24 R4 rear tires

■

Rear wheel spacers for use with chains

■

BACKHOE

Backhoe with standard dipperstick, 15 ft. 10 in. digging depth

●

Backhoe controls

Two-lever (Deere) controls

●

Three-lever (Case) controls

■

Four-lever (Ford) controls

■

SAE excavator two-lever controls

■

Backhoe transport lock lever

●

Swing lock pin stored in operator’s station

●

Stabilizer valve with two-direction anti-drift valves

●

Pivoting stabilizers

With dirt pads

●

With reversible pads

■

Stabilizer cylinder guards

■

Backhoe buckets

Less bucket, with bucket pins

●

Standard duty with lift loops

■

410E

Fuel gauge, illuminated electric

●

Gauge package, illuminated electric

■

Engine coolant temperature / Transmission oil temper-

ature / Alternator volts / Fuel gauge

Monitor system with audible and visual warning

●

Engine air filter restriction indicator / Alternator indi-

cator / Engine coolant temperature indicator with
audible warning / Engine oil pressure indicator with
audible warning / Hydraulic filter restriction indica-
tor / Torque converter oil temperature indicator /
Parking brake on/off indicator with audible warning /
Seat belt indicator / Mechanical-front-wheel-drive
on/off indicator / Beacon on/off indicator / Hydraulic
oil temperature indicator

Seats and seat belts

Non-suspension vinyl swivel seat without armrests

●

Suspension vinyl swivel seat with armrests and lumbar

■

support

Suspension fabric swivel seat with armrests and lumbar

■

support

Air suspension vinyl swivel seat with armrests and

■

lumbar support

Air suspension fabric swivel seat with armrests and

■

lumbar support

2-in. seat belt with retractors

●

3-in. seat belt with retractors

■

Cab

■

Headliner

●

Dome light

●

Left cab door

●

Right cab door

■

Tinted safety glass

●

Two front and one rear windshield wipers

●

Front windshield washer

■

Fresh air intake heater/defroster/pressurizer

●

40,000 Btu/hr. (11.7 kW) heater

Air conditioning

■

26,000 Btu/hr. (7.6 kW) output / CFC-free R134a

refrigerant

65-amp alternator

●

95-amp alternator

■

AM/FM/weatherband radio

■

Ride control

■

OVERALL VEHICLE

One-piece unitized construction mainframe

●

Vehicle tiedowns, two front and one rear

●

Remote grease bank for front axle

●

Rigid mounted front bumper

●

Front counterweights

400 lb. (181 kg)

■

650 lb. (295 kg)

■

900 lb. (408 kg)

■

1,150 lb. (522 kg)

■

1,400 lb. (635 kg)

■

Fuel tank, 36 gal. (136 L), ground level fueling

●

Engine sideshields with sliding service access door

●

Front grille screen

■

Vandal protection for instrument panel, engine access

●

doors, and fuel tank

Reverse warning alarm

●

Switchable to 97 dB(A) or 111 dB(A)

Dent-resistant rear fenders

●

Rear fender extensions

■

Front fenders*

■

SMV emblem

■

Rental decal kit

■

Special color paint*

■

Quarter cab*

■

Heavy duty with lift loops

■

Severe duty with lift loops

■

Backhoe bucket coupler for “C” and “D” series John

■

Deere buckets, Case buckets, and Cat buckets

Extendible dipperstick, 4 ft. extension

■

Auxiliary backhoe valve for swingers, thumbs, etc.

■

Auxiliary backhoe valve for hammers, compactors

■

Auxiliary backhoe plumbing for hammers, compactors

■

SAE controlled load lowering device valves

■

LOADER

Hydraulic self leveling

●

Return-to-dig feature

●

Single-lever control with electric clutch cutoff switch

●

Bucket-level indicator

●

Loader boom service lock

●

Auxiliary loader hydraulics with two-lever control

■

Loader front coupler

■

Loader buckets

Less bucket, with bucket pins

●

Heavy-duty buckets with bolt-on cutting edge, skid

■

plates, and lift loops

Multipurpose bucket with bolt-on cutting edge, skid

■

plates, and lift loops

HYDRAULIC SYSTEM

42 gpm (159 L/min.) axial piston pump, PCLS system

●

Independent hydraulic reservoir

●

Hydraulic oil cooler

●

“O”-ring face seal connectors

●

10-micron vertical spin-on filter

●

ELECTRICAL

12-volt system

●

65-amp alternator

●

Single battery with 150-min. reserve capacity and 750 CCA

●

Dual batteries with 300-min. reserve capacity and 1,500 CCA

■

Positive terminal battery cover

●

Blade-type multi-fused circuits

●

By-pass start safety cover on starter

●

LIGHTS

Two front halogen driving/work lights, 32,500 candle-

●

power each

Two additional front halogen work lights, 32,500 candle-

■

power each

Two rear halogen work lights, 32,500 candlepower each

●

Two front and two rear turn signal/flashing

●

Two rear stop and tail

●

Two rear reflectors

●

Rotating beacon

■

OPERATOR’S STATION

Modular-design ROPS/FOPS canopy with molded roof

●

Isolation mounted / Conforms to SAE J1040

Left and right front access

●

Slip-resistant steps and ergonomically located handholds

●

Molded floor mat

●

Headliner

●

Coat hook

●

Built-in beverage and Thermos

bottle holders

●

Built-in Operator’s Manual storage compartment with manual

●

Interior rearview mirror

●

Outside rearview mirrors

■

Hand throttle with fuel economy setting at 2,100 rpm

●

Suspended foot throttle

●

Tilt steering

■

Horn

●

Key start switch with electric fuel shutoff

●

Tachometer/hourmeter, illuminated electric

●

A D D I T I O N A L E Q U I P M E N T

KEY:

●

Standard equipment

■

Optional or special equipment

*See your John Deere dealer for further information.

Net engine power is with standard equipment including air cleaner, exhaust system,
alternator, and cooling fan, at standard conditions per SAE J1349 and DIN 70 020,
using No. 2-D fuel at 35 API gravity. No derating is required up to 10,000 feet (3050 m).
Gross power is without cooling fan.

Specifications and design subject to change without notice. Wherever applicable, specifications are in
accordance with SAE standards. Except where otherwise noted, these specifications are based on a unit
with 19.5L-24, 10 PR R4 rear tires, 11L-16, 12 PR F3 front tires, 1.30 cu. yd. (1.00 m

) loader bucket, and

24 in. x 7.5 cu. ft. (610 mm x 0.21 m

) backhoe bucket.
