102
English
Amplifier Section—CA-UXA10DVD
Output Power (IEC 268-3):
74 W (37 W + 37 W) at 6
Ω
(10% THD)
Analog input
AUX:
Sensitivity/Impedance (at 1 kHz)
500 mV/47 k
Ω
(at “LEVEL 1”)
200 mV/47 k
Ω
(at “LEVEL 2”)
Digital input*
OPTICAL DIGITAL IN: –21 dBm to –15 dBm
(660 nm
±30 nm)
* Corresponding to Linear PCM (with 32 kHz/44.1 kHz/48 kHz
sampling frequency)
Digital output
DVD OPTICAL DIGITAL OUT: –21 dBm to –15 dBm
(660 nm
±30 nm)
VIDEO OUT:
Color system:
NTSC/PAL selectable
Composite:
1 V(p-p)/75
Ω
S-video:
Y (luminance)
1 V(p-p)/75
Ω
C (chrominance, burst)
0.286 V(p-p)/75
Ω
Speaker Terminals:
6
Ω
– 16
Ω
Tuner
FM tuning range:
87.50 MHz—108.00 MHz
AM tuning range:
531 kHz—1 710 kHz
(at 9 kHz channel spacing)
530 kHz—1 710 kHz
(at 10 kHz channel spacing)
DVD player
Readable discs:
DVD VIDEO,
Super Video CD,
Video CD,
Audio CD
Dynamic range:
98 dB
Horizontal resolution:
500 lines
Wow and flutter:
Immeasurable
MD recorder
Audio playing system:
MiniDisc digital audio system
Recording system:
Magneto-optical overwrite
system
Reading system:
Non-contact, semiconductor
laser pickup
Recording/Playback time (when using a 80-minute MD)
SP:
80 minutes
LP2:
160 minutes
LP4:
320 minutes
Sampling frequency:
44.1 kHz
Audio compression system:
ATRAC (Adaptive TRansform
Acoustic Coding)/ATRAC3
(
)
Specifications
Design and specifications are subject to change without notice.
Cassette deck
Frequency response:
Normal (type I):
60 Hz—14 000 Hz
Wow and flutter:
0.15 % (WRMS)
General
Power requirement:
AC 220 V
, 50 Hz
Power consumption:
At operation:
105 W
On standby:
15 W
1.2 W (in power save mode)
Dimensions (W/H/D) (approx.):
185 mm x 265 mm x 316 mm
Mass (approx.):
6.9 kg
Supplied accessories
See “Unpacking” on page 8.
Speaker Section—SP-UXA10DVD
Type:
3-way bass-reflex
magnetically shielded type
Speakers:
Woofer
10 cm cone x1
Midrange 4 cm cone x1
Tweeter
2 cm dome x1
Impedance:
6
Ω
Frequency range:
55 Hz to 20 kHz
Sound pressure level:
85.5 dB/W•m
Dimensions (W/H/D) (approx.):
153 mm x 266 mm x 211.5 mm
Mass (approx.):
3.0 kg each
US and foreign patents licensed from Dolby Laboratories.
