Serviceability CT315
In-cab boom lock secures loader before exiting operator seat; operator’s station pivots for service access in minutes; serpentine belt and hydraulic valve lifters never
require adjustment; rear-door-mounted oil cooler for easy radiator and cooler clean-out; cooling system swing-out hydraulic oil cooler
Diagnostics Computerized in-cab monitor information
Refill Capacities
Fuel Tank 17.5 gal. (66 L)
Cooling System 7 qt. (6.2 L)
Engine Oil with Filter 9.5 qt. (9 L)
Hydraulic Tank 5 gal. (19 L)
Operating Weights
Base Machine 6,800 lb. (3087 kg)
Dimensions
A Length without Bucket 8 ft. 0 in. (2.44 m)
B Length with Bucket (66-in. [1676 mm] foundry) 10 ft. 4 in. (3.17 m)
C Width without Bucket (12.6-in. [320 mm] track) 5 ft. 1 in. (1.54 m)
D Height to Top of ROPS 6 ft. 5 in. (1.96 m)
E Height to Hinge Pin 9 ft. 2 in. (2.78 m)
F Dump Height 7 ft. 7 in. (2.31 m)
G Dump Reach
Heavy-Duty Foundry Bucket 17.4 in. (442 mm)
Heavy-Duty Construction Bucket 23 in. (577 mm)
H Ground Clearance 7.8 in. (198 mm)
I Angle of Departure 25.25 deg.
J Front Turn Radius 6 ft. 7 in. (2.00 m)
K Dump Angle (full lift height) 40 deg.
L Bucket Rollback (ground level) 30 deg.
Tipping Load 4,412 lb. (2003 kg)
SAE Rated Operating Capacity (foundry bucket)
@ 35% of Tipping Load 1,500 lb. (681 kg)
@ 50% of Tipping Load 2,206 lb. (1002 kg)
Boom Breakout 2,700 lb. (1226 kg)
Bucket Breakout Force
Foundry Bucket 3,300 lb. (1498 kg)
Dirt Bucket 2,178 lb. (989 kg)
Specifications
Engine CT315
Manufacturer and Model John Deere PowerTech TM 4024T
Non-Road Emission Standards Certified to EPA Interim Tier 4 emissions
Cylinders 4
Net Horsepower 45 net hp (33.5 kW)
Gross Horsepower 49 gross hp (36.5 kW)
Displacement 149 cu. in. (2.4 L)
Rated Engine Speed 2,400 rpm
Gross Peak Torque 139 lb.-ft. (188 Nm)
Torque Rise 32%
Aspiration Turbocharged
Air Cleaner Dry dual element
Cooling
Fan Type Auto-tensioned serpentine belt drive
Engine Coolant Rating –34 deg. F (–37 deg. C)
Powertrain
High-drive planetary-reduction gearbox
Pump Axial piston hydrostatic
Controls Manual
Travel Speed (single speed, standard) 6.0 mph (9.7 km/h)
System High-Pressure Relief 5,000 psi (34 474 kPa)
Brake Integral, automatic, spring applied, hydraulically released, wet disc
Undercarriage
Rubber Tracks New-generation smooth-ride long-life rubber tracks with steel inserts
Standard Track Width 12.6 in. (320 mm)
Ground Pressure (standard 12.6-in. [320 mm] track) 4.8 psi (33 kPa)
Track Rollers (per side) 3 triple-flange smooth-ride all-steel rollers
Track Idlers (per side) Double-flange front, single-flange rear
Bearings/Seals (rollers/idlers) Heavy-duty journal bearings and metal face seals
Tractive Effort 8,000 lbf (3629 kgf)
Hydraulics
Standard Pump Flow 16 gpm (61 L/m)
System Pressure at Couplers 3,450 psi (23 787 kPa)
Hydraulic Horsepower (standard flow [calculated]) 35 hp (26.1 kW)
Cylinders
John Deere heat-treated, chrome-plated, polished cylinder rods; hardened steel (replaceable bushings) pivot pins
Electrical
Voltage 12 volt
Battery Capacity 750 CCA (optional 925 CCA)
Alternator Rating 70 amp
Lights Halogen, 2 front and 1 rear
Operator’s Station
ROPS (ISO3471)/FOPS (ISO3449) structure with quick pivot standard
