17
Superimpose
This function, switchable between ON and OFF, determines
whether or not operational indicators will appear on screen.
ACCESS MAIN MENU
SCREEN
1
Press MENU.
ACCESS FUNCTION SET
SCREEN
2
Place the arrow next to "FUNCTION SET" by pressing
CH
5∞, then press OK.
ACCESS SUPERIMPOSE
SCREEN
3
Place the arrow next to
"SUPERIMPOSE" by
pressing CH
5∞, then
press OK.
● "2ND AUDIO" and
"AUDIO MONITOR" will
appear with HR-A53U
only.
SELECT MODE
4
Place the arrow next to
"ON" or "OFF" by pressing
CH
5∞.
RETURN TO NORMAL
SCREEN
5
Press MENU as many times as necessary.
NOTE:
If you engage the Record Pause mode, RECORD/PAUSE (or ITR
followed by the elapsed time/PAUSE) is displayed whether
"SUPERIMPOSE" is set to "ON" or "OFF".
The superimposed indication on the TV screen tells you what the VCR is doing.
Tuned-in channel or AUX(iliary) mode
When the channel is changed, the new
channel is displayed on the screen for 5
seconds.
Clock time
Tape position indicator
Operation mode
When the operation mode is changed,
the new mode is displayed — RECORD
(5 sec.), PLAY (5 sec.), FF/REW (5 sec.
when engaged from Stop mode),
RECORD PAUSE (for as long as Pause is
engaged), and ITR *:** (5 sec.).
B E + + +
"Cassette Loaded" mark
When a cassette is loaded, the mark is
displayed for 5 seconds. It blinks when the
VCR's EJECT button is pushed.
Tape speed indicator
INDEX indication
Counter reading
To recall an indication
1 Press OSD.
Ⅲ All indications corresponding to the current status are
displayed for 5 seconds, leaving the counter information,
and RECORD/PAUSE if in the Record Pause mode, on
the screen. (No indication during still and search.)
2 Press OSD again to clear the display.
Audio mode indicators
(HR-A53U only)
FUNCTION
AUTO TIMER
=SUPERIMPOSE
2ND AUDIO
AUDIO MONITOR
PRESS ( 5,∞), THEN (OK)
PRESS (MENU) TO END
SUPERIMPOSE
=ON
OFF
PRESS ( 5,∞) TO SELECT
PRESS (MENU) TO END
CH 125 RECORD
THU 12:00 AM PAUSE
] SP
INDEX-1
NORM
HI–FI COUNT
–1:23:45
q
2 3
6 5 / 8
MENU
CH
OK
3
¶ 7 8
1 ¡
1 2 3
4 5 6
7 8
0
9
MENU
OK CH
OSD
