9
Warnings
4) Clear a fl at, soft area on which to lay the TV on it's back. Two
people can gently lay back the TV. Please use extra care as
any shock or impact may damage the TV. (Do not lay it on it's
front to avoid damaging the screen.)
1) Remove the cover on the rear pedestal towards the upper part.
2) Loosen 6 Phillips type screws.
3) Slide out the rear pedestal as shown, under the TV.
6) Gently return the TV to an upright position.
To remove the front and rear pedestal
7) Attach the cover again.
6) Tighten 6 Phillips type screws (included) into the holes.
5) Remove the cover on the rear pedestal towards the upper part.
5) Loosen 8 Phillips type screws. Then,
remove the front pedestal from the bottom
of the TV.
