JL Audio Stealthbox SB-GM-SLVCNSL/10W3 - Manual (Page 6)

Sheet SKU#011142 Revision 8/15/00
This completes the installation.
Specifications:
Enclosure Type: Acoustic Suspension (Sealed)
Driver Type: JL AUDIO 10W3-D6 Subwoofer
Cont. Power Handling: 250 Watts
Nominal Impedance: 3
Ω
10369 N. Commerce Pkwy, Miramar, Florida 33025-3921 Voice: (954) 443-1100 Fax: (954) 443-1111
Supplied Hardware:
(4) 1/4" X 2" Bolts
(4) 1/4" Washers
(4) #8 Flat Head Screws
(4) 1/4" Lock Washers
(1) Console Insert
SB-GM-SLVCNSL/10W3-D6, JL AUDIO, Inc 2000 • Page 6
STEP 21: Place the console body over the Stealthbox.
STEP 22: Secure the body with the OEM screws into the dash
extension.
STEP 23: Drill 7/64" holes into the Stealthbox at the four
locations of the holes drilled into the console body.
STEP 24: Secure the console body to the Stealthbox through
these holes with the supplied screws.
