G-2
UX-V30R 10 cm
15 cm
15 cm
15 cm 1 cm 1 cm
TAPE FM/AM CD
VERTICAL DISC LOADING MECHANISM
COMPACT DIGITAL AUDIO
MICRO COMPONENT SYSTEM UX-V30R
Front view Side view
Caution: Proper Ventilation
To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows:
1 Front:
No obstructions and open spacing.
2 Sides/ Top/ Back:
No obstructions should be placed in the areas shown by the dimensions below.
3 Bottom:
Place on the level surface. Maintain an adequate air path for ventilation by placing on a stand with a height of 10 cm
or more.
15 cm
UX-V30R
15 cm
