Page 23
Installation 23
IIT Camera System Manual
3.4 Flash
The flash is optionally used for vehicle illumination at night. The electrical control signal connection
to the IIT camera is from X1 on the IIT I/O Board. The signals are:
Figure 13. IIT I/O Board Flash Connector X1 signals
The electrical signals are the same as the VIS-CAM Systems (350/400) flash connector and the
connections to the flash is as described in section 3.4 of the VIS-CAM System Installation manual.
