Lift Capacities
(continued)
135D
Boldface italic type indicates hydraulic-limited capacities; lightface type indicates stability-limited capacities, in lb. (kg). Ratings at bucket lift hook; machine equipped with
0.37-cu.-yd. (0.28 m
3
) bucket, 15-ft. 1-in. (4.6 m) boom, and standard gauge, and situated on firm, uniform surface. Total load includes weight of cables, hook, etc. Figures
do not exceed 87% of hydraulic capacities or 75% of weight needed to tip machine. All capacities are based on SAE J1097.
Load Point
5 ft. (1.52 m)
10 ft. (3.05 m)
15 ft. (4.57 m)
20 ft. (6.10 m)
25 ft. (7.62 m)
Height
Over Front
Over Side
Over Front
Over Side
Over Front
Over Side
Over Front
Over Side
Over Front
Over Side
With 9-ft. 11-in. (3.01 m) arm and 24-in. (600 mm) shoes, without blade
20 ft. (6.10 m)
5,129 (2326)
5,129 (2326)
3,764 (1707) 3,764 (1707)
15 ft. (4.57 m)
5,342 (2423)
5,342 (2423)
5,603 (2541) 4,812 (2183)
10 ft. (3.05 m)
5,477 (2484)
5,477 (2484)
6,709 (3043)
6,709 (3043)
6,215 (2819) 4,644 (2106) 4,011
(1819) 3,010 (1365)
5 ft. (1.52 m)
9,350
(4241)
7,013 (3181)
6,168 (2798) 4,376 (1985) 4,176 (1894) 2,914 (1322)
Ground
Line
10,793 (4896)
10,793 (4896)
9,374 (4252)
6,463 (2932)
5,889 (2671) 4,117 (1867) 4,061 (1842) 2,805 (1272)
–5 ft. (–1.52 m)
6,419 (2912)
6,419 (2912)
15,472 (7018)
11,797 (5351)
9,067 (4113)
6,188 (2807)
5,718 (2594) 3,958 (1795)
–10 ft. (–3.05 m) 14,078 (6386)
14,078 (6386)
16,229 (7361)
11,909 (5402)
9,036 (4099)
6,160 (2794)
5,707 (2589) 3,949 (1791)
–15 ft. (–4.57 m)
11,461 (5199)
11,461 (5199)
7,798 (3537)
6,377 (2893)
With 8-ft. 3-in. (2.52 m) arm and 24-in. (600 mm) shoes, with 8-ft. 2-in. (2.49 m) blade
20 ft. (6.10 m)
6,263 (2841)
6,263 (2841)
15 ft. (4.57 m)
6,368 (2888)
6,368 (2888)
6,073 (2755) 5,183 (2351)
10 ft. (3.05 m)
9,119 (4136)
9,119 (4136)
7,951 (3607)
7,951 (3607)
6,859 (3111) 5,047 (2289)
5 ft. (1.52 m)
10,242
(4646)
7,548 (3424)
7,760 (3520) 4,810 (2182)
Ground
Line
11,825 (5364)
7,092 (3217)
8,477 (3845) 4,594 (2084)
–5 ft. (–1.52 m)
6,904 (3132)
6,904 (3132)
16,795 (7618)
13,101 (5943)
11,921 (5407)
6,907 (3133)
8,471 (3842) 4,484 (2034)
–10 ft. (–3.05 m)
14,858
(6739)
13,294 (6030)
10,399 (4717)
6,947 (3151)
6,917 (3137) 4,544 (2061)
–15 ft. (–4.57 m)
5,738 (2603)
5,738 (2603)
With 9-ft. 11-in. (3.01 m) arm and 24-in. (600 mm) shoes, with 8-ft. 2-in. (2.49 m) blade on ground
20 ft. (6.10 m)
5,129 (2326)
5,129 (2326)
3,764 (1707) 3,764 (1707)
15 ft. (4.57 m)
5,342 (2423)
5,342 (2423)
5,603 (2541) 5,247 (2380)
10 ft. (3.05 m)
5,477 (2484)
5,477 (2484)
6,709 (3043)
6,709 (3043)
6,215 (2819) 5,079 (2304) 4,011
(1819) 3,344 (1517)
5 ft. (1.52 m)
9,350
(4241)
7,636 (3464) 7,236
(3282) 4,810 (2182) 5,504 (2497) 3,247 (1473)
Ground
Line
10,793 (4896)
10,793 (4896)
11,321 (5135)
7,087 (3215)
8,149 (3696) 4,552 (2065) 5,967 (2707) 3,138 (1423)
–5 ft. (–1.52 m)
6,419 (2912)
6,419 (2912)
15,472 (7018)
12,900 (5851) 11,909
(5402) 6,812 (3090)
8,453 (3834) 4,393 (1993)
–10 ft. (–3.05 m) 14,078 (6386)
14,078 (6386)
16,229 (7361)
13,013 (5903) 10,957
(4970) 6,784 (3077)
7,628 (3460) 4,383 (1988)
–15 ft. (–4.57 m)
11,461 (5199)
11,461 (5199)
7,798 (3537)
7,001 (3176)
With 8-ft. 3-in. (2.52 m) arm and 28-in. (700 mm) shoes, without blade
20 ft. (6.10 m)
6,263 (2841)
6,263 (2841)
15 ft. (4.57 m)
6,368 (2888)
6,368 (2888)
6,073 (2755) 4,827 (2189)
10 ft. (3.05 m)
9,119 (4136)
9,119 (4136)
7,951 (3607)
7,621 (3457)
6,508 (2952)
4,691 (2128)
5 ft. (1.52 m)
10,016 (4543)
7,037 (3192)
6,253 (2836) 4,454 (2020)
Ground
Line
9,506 (4312)
6,581 (2985)
6,020 (2731) 4,238 (1922)
–5 ft. (–1.52 m)
6,904 (3132)
6,904 (3132)
16,795 (7618)
12,197 (5532)
9,300 (4218)
6,396 (2901)
5,900 (2676) 4,128 (1872)
–10 ft. (–3.05 m)
14,858
(6739)
12,390 (5620)
9,345 (4239)
6,437 (2920)
5,965 (2706) 4,188 (1900)
–15 ft. (–4.57 m)
5,738 (2603)
5,738 (2603)
With 9-ft. 11-in. (3.01 m) arm and 28-in. (700 mm) shoes, without blade
20 ft. (6.10 m)
5,129 (2326)
5,129 (2326)
3,764 (1707) 3,764 (1707)
15 ft. (4.57 m)
5,342 (2423)
5,342 (2423)
5,603 (2541) 4,891 (2219)
10 ft. (3.05 m)
5,477 (2484)
5,477 (2484)
6,709 (3043)
6,709 (3043)
6,215 (2819) 4,723 (2142) 4,011
(1819) 3,071 (1393)
5 ft. (1.52 m)
9,350
(4241)
7,126 (3232)
6,263 (2841) 4,454 (2020) 4,248 (1927) 2,974 (1349)
Ground
Line
10,793 (4896)
10,793 (4896)
9,515 (4316)
6,576 (2983)
5,984 (2714) 4,196 (1903) 4,132 (1874) 2,865 (1300)
–5 ft. (–1.52 m)
6,419 (2912)
6,419 (2912)
15,472 (7018)
11,997 (5442)
9,208 (4177)
6,301 (2858)
5,812 (2636) 4,037 (1831)
–10 ft. (–3.05 m) 14,078 (6386)
14,078 (6386)
16,229 (7361)
12,109 (5493)
9,177 (4163)
6,273 (2845)
5,802 (2632) 4,027 (1827)
–15 ft. (–4.57 m)
11,461 (5199)
11,461 (5199)
7,798 (3537)
6,490 (2944)
With 8-ft. 3-in. (2.52 m) arm and 28-in. (700 mm) shoes, with 8-ft. 10-in. (2.69 m) blade
20 ft. (6.10 m)
6,263 (2841)
6,263 (2841)
15 ft. (4.57 m)
6,368 (2888)
6,368 (2888)
6,073 (2755) 5,262 (2387)
10 ft. (3.05 m)
9,119 (4136)
9,119 (4136)
7,951 (3607)
7,951 (3607)
6,859 (3111) 5,125 (2325)
5 ft. (1.52 m)
10,242
(4646)
7,661 (3475)
7,760 (3520) 4,889 (2218)
Ground
Line
11,825 (5364)
7,205 (3268)
8,477 (3845) 4,673 (2120)
–5 ft. (–1.52 m)
6,904 (3132)
6,904 (3132)
16,795 (7618)
13,301 (6033)
11,921 (5407)
7,020 (3184)
8,471 (3842) 4,562 (2069)
–10 ft. (–3.05 m)
14,858
(6739)
13,494 (6121)
10,399 (4717)
7,061 (3203)
6,917 (3137) 4,623 (2097)
–15 ft. (–4.57 m)
5,738 (2603)
5,738 (2603)
