CO N N E C T I N G
SINGLE-WIRING
For single-wire connections, the terminal jumpers should be attached as shown in
the illustration.
BI-WIRING
If you’d like to use a bi-wiring arrangement, make sure you remove all the terminal
jumpers before you connect up your loudspeaker cables.
BI-AMPING
In a bi-amped system, make sure you remove the terminal jumpers before con-
necting up your cables. The top pair of terminals drive the tweeter while the pair
underneath drive the bass and midrange units.
If you choose this option, we recommend you use identical amplifi ers for both ter-
minals.
AMPLIFIER
AMPLIFIER 1
AMPLIFIER 2
AMPLIFIER
