41
ENGLISH
AUDIO AMPLIFIER SECTION
Maximum Power Output:
Front: 50 W per channel
Rear: 50 W per channel
Continuous Power Output (RMS):
Front: 19 W per channel into 4 Ω , 40 Hz
to 20 000 Hz at no more than
0.8% total harmonic distortion.
Rear: 19 W per channel into 4
Ω
, 40 Hz
to 20 000 Hz at no more than
0.8% total harmonic distortion.
Load Impedance: 4
Ω
(4
Ω
to 8
Ω
allowance)
Equalizer Control Range:
LOW: ±12 dB (50 Hz, 80 Hz, 120 Hz)
MID: ±12 dB (700 Hz, 1 kHz, 2 kHz)
HIGH: ±12 dB (8 kHz, 12 kHz)
Frequency Response: 40 Hz to 20 000 Hz
Signal-to-Noise Ratio: 70 dB
Line-In Level/Impedance:
KD-SH77R : 1.5 V/20 k
Ω
load
Line-Out Level/Impedance:
KD-SH55R : 2.0 V/20 k
Ω
load (full scale)
KD-SH77R : 4.0 V/20 k
Ω
load (full scale)
Output Impedance: 1 k
Ω
auxiliary input jack : (3.5 mm dia. stereo mini jack)
TUNER SECTION
Frequency Range:
FM: 87.5 MHz to 108.0 MHz
AM: (MW) 522 kHz to 1 620 kHz
(LW)
144 kHz to 279 kHz
[FM Tuner]
Usable Sensitivity: 11.3 dBf (1.0 µV/75
Ω
)
50 dB Quieting Sensitivity:
16.3 dBf (1.8 µV/75
Ω
)
Alternate Channel Selectivity (400 kHz):
65 dB
Frequency Response: 40 Hz to 15 000 Hz
Stereo Separation: 30 dB
Capture Ratio: 1.5 dB
[MW Tuner]
Sensitivity: 20 µV
Selectivity: 35 dB
[LW Tuner]
Sensitivity: 50 µV
CD PLAYER SECTION
Type: Compact disc player
Signal Detection System: Non-contact optical
pickup (semiconductor laser)
Number of channels: 2 channels (stereo)
Frequency Response: 5 Hz to 20 000 Hz
Dynamic Range:
98 dB
Signal-to-Noise Ratio: 102 dB
Wow and Flutter: Less than measurable limit
GENERAL
Power Requirement:
Operating Voltage: DC 14.4 V
(11 V to16 V allowance)
Grounding System: Negative ground
Allowable Operating Temperature: 0°C to +40°C
Dimensions (W
× H × D):
Installation Size: 182 mm × 52 mm × 161 mm
Panel Size: 188 mm × 58 mm × 17 mm
Mass: 1.8 kg (excluding accessories)
Design and specifications subject to change without
notice.
SPECIFICATIONS
