61
ENGLISH
ZOOM FOCUS
T
W
MENU
ENTER EXIT
VIC SELECT 1 2 3 KEY STONE OPERATE HIDE STAND BY
REMOTE CONTROL RS-232C OUT RS-232C IN
R G B V H/CS
RGB Analog VIC
Pin assignment (Specifications for terminals)
Specifications (Cont.)
Outside dimensions
■ Top
■ Front ■ Side
838 (33)
660 (26)
720 (28- 3 / 8 ) 42 (1- 11 / 16 )
838 (33)
230 (
9
- 1
/ 16
)
Unit: mm (inch)
720 (28- 3 / 8 )
30 (1- 3 / 16 )
30 (1- 3 / 16 )
φ 50 (φ 2)
951 (37- 1 / 2 )
42 (1- 11 / 16 )
18 ( 3 / 4 ) 18 ( 3 / 4 )
59 (2-
3
/ 8
)
30 (1- 3 / 16 ) 30 (1- 3 / 16 )
820 (32- 5 / 16 )
■ RS-232C terminal
Pin number Signal name
1 N/C
2 RD
3 TD
4 N/C
5 GND
Pin number Signal name
6 N/C
7 N/C
8 N/C
9 N/C
3
5
6
9
4
8
2
1
7
820 (32- 5 / 16 )
368
(14-
1
/ 2
) ~
420
(16-
9
/ 16
)
420
(16-
9
/ 16
) ~
472
(18-
5
/ 8
)
59 (2-
3
/ 8
)
(To be continued on the next page)
