160C LC Lift Capacities
Boldface italic type indicates hydraulic-limited capacities; lightface type indicates stability-limited capacities, in lb. (kg). Ratings at bucket lift hook, machine equipped with 0.78-cu. yd. (0.60 m 3 ),
36-in. (900 mm) wide, 1,096-lb. (497 kg) bucket; and situated on firm, uniform supporting surface. Total load includes weight of cables, hook, etc. Figures do not exceed 87 percent of hydraulic
capacities or 75 percent of weight needed to tip machine. Ratings are based on SAE J1097.
Load Point 5 ft. (1.52 m) 10 ft. (3.05 m) 15 ft. (4.57 m) 20 ft. (6.10 m) 25 ft. (7.62 m)
Height Over Front Over Side Over Front Over Side Over Front Over Side Over Front Over Side Over Front Over Side
With 8-ft. 6-in. (2.60 m) arm and 24-in. (600 mm) shoes
15 ft. (4.57 m) 6,629 (3007) 5,944 (2696)
10 ft. (3.05 m) 13,261 (6015) 13,261 (6015) 9,070 (4114) 9,070 (4114) 7,636 (3464) 5,659 (2567) 5,083 (2306) 3,704 (1680)
5 ft. (1.52 m) 12,214 (5540) 8,322 (3775) 8,694 (3944) 5,291 (2400) 5,982 (2713) 3,565 (1617)
Ground Line 13,249 (6010) 7,752 (3516) 8,361 (3793) 4,988 (2263) 5,842 (2650) 3,435 (1558)
–5 ft. (–1.52 m) 17,223 (7812) 14,626 (6634) 13,021 (5906) 7,556 (3427) 8,197 (3718) 4,840 (2195)
–10 ft. (–3.05 m) 18,856 (8553) 18,856 (8553) 20,665 (9374) 14,910 (6763) 13,101 (5943) 7,624 (3458) 8,250 (3742) 4,888 (2217)
–15 ft. (–4.57 m) 16,081 (7294) 15,494 (7028) 11,152 (5059) 7,987 (3623)
With 8-ft. 6-in. (2.60 m) arm and 28-in. (700 mm) shoes
15 ft. (4.57 m) 6,629 (3007) 6,023 (2732)
10 ft. (3.05 m) 13,261 (6015) 13,261 (6015) 9,070 (4114) 9,070 (4114) 7,636 (3464) 5,738 (2603) 5,083 (2306) 3,765 (1708)
5 ft. (1.52 m) 12,214 (5540) 8,436 (3827) 8,819 (4000) 5,370 (2436) 6,076 (2756) 3,626 (1645)
Ground Line 13,437 (6095) 7,866 (3568) 8,486 (3849) 5,068 (2299) 5,935 (2692) 3,495 (1585)
–5 ft. (–1.52 m) 17,223 (7812) 14,828 (6726) 13,209 (5992) 7,669 (3479) 8,322 (3775) 4,919 (2231)
–10 ft. (–3.05 m) 18,856 (8553) 18,856 (8553) 20,665 (9374) 15,112 (6855) 13,289 (6028) 7,738 (3510) 8,375 (3799) 4,967 (2253)
–15 ft. (–4.57 m) 16,081 (7294) 15,695 (7119) 11,152 (5059) 8,100 (3674)
With 10-ft. 2-in. (3.10 m) arm and 24-in. (600 mm) shoes
20 ft. (6.10 m) 5,585 (2533) 5,585 (2533)
15 ft. (4.57 m) 5,825 (2642) 5,825 (2642) 6,073 (2755) 3,802 (1725)
10 ft. (3.05 m) 7,871 (3570) 7,871 (3570) 6,921 (3139) 5,797 (2630) 6,046 (2742) 3,621 (1642)
5 ft. (1.52 m) 11,141 (5054) 8,544 (3876) 8,442 (3829) 5,390 (2445) 5,860 (2658) 3,448 (1564)
Ground Line 10,402 (4718) 10,402 (4718) 13,358 (6059) 7,840 (3556) 8,413 (3816) 5,031 (2282) 5,760 (2613) 3,356 (1522)
–5 ft. (–1.52 m) 7,664 (3476) 7,664 (3476) 17,080 (7747) 14,435 (6548) 12,995 (5895) 7,525 (3413) 8,182 (3711) 4,822 (2187)
–10 ft. (–3.05 m) 16,271 (7381) 16,271 (7381) 21,897 (9932) 14,628 (6635) 12,977 (5886) 7,510 (3407) 8,155 (3699) 4,797 (2176)
–15 ft. (–4.57 m) 18,222 (8265) 15,121 (6859) 12,537 (5687) 7,763 (3521)
With 10-ft. 2-in. (3.10 m) arm and 28-in. (700 mm) shoes
20 ft. (6.10 m) 5,585 (2533) 5,585 (2533)
15 ft. (4.57 m) 5,825 (2642) 5,825 (2642) 6,073 (2755) 3,862 (1752)
10 ft. (3.05 m) 7,871 (3570) 7,871 (3570) 6,921 (3139) 5,876 (2665) 6,140 (2785) 3,681 (1670)
5 ft. (1.52 m) 11,141 (5054) 8,657 (3927) 8,442 (3829) 5,469 (2481) 5,953 (2700) 3,509 (1592)
Ground Line 10,402 (4718) 10,402 (4718) 13,546 (6144) 7,954 (3608) 8,538 (3873) 5,111 (2318) 5,854 (2655) 3,416 (1549)
–5 ft. (–1.52 m) 7,664 (3476) 7,664 (3476) 17,080 (7747) 14,637 (6639) 13,183 (5980) 7,639 (3465) 8,307 (3768) 4,901 (2223)
–10 ft. (–3.05 m) 16,271 (7381) 16,271 (7381) 21,897 (9932) 14,829 (6726) 13,165 (5972) 7,624 (3458) 8,280 (3756) 4,876 (2212)
–15 ft. (–4.57 m) 18,222 (8265) 15,323 (6951) 12,537 (5687) 7,877 (3573)
120C Buckets
A full line of buckets is offered to meet a wide variety of applications. The buckets have an adjustable bushing for side clearance, with the exception of the ditching bucket. Tooth selection includes
either the John Deere Fanggs
® or the ESCO (Helilok) Standard tooth. Replaceable cutting edges are available through John Deere parts. Optional side cutters add 6 inches (150 mm) to bucket widths.
Bucket Bucket Bucket Arm Dig Force Arm Dig Force Bucket
Type Bucket Width Capacity* Weight Dig Force 8 ft. 3 in. (2.52 m) 9 ft. 11 in. (3.01 m) Tip Radius No. Teeth
in. mm cu. yd. m 3 lb. kg lb. kN lb. kN lb. kN in. mm
General-Purpose 18 460 0.34 0.26 723 328 18,675 83.1 13,639 60.7 12,644 56.3 50.0 1270 3
Plate Lip 24 610 0.50 0.38 893 405 18,675 83.1 13,639 60.7 12,644 56.3 50.0 1270 4
30 760 0.64 0.49 1,066 484 18,675 83.1 13,639 60.7 12,644 56.3 50.0 1270 4
36 915 0.78 0.60 1,081 490 18,675 83.1 13,639 60.7 12,644 56.3 50.0 1270 5
42 1065 0.79 0.60 926 420 21,463 92.3 14,620 65.0 13,172 58.6 43.5 1105 6
42 1065 0.92 0.70 1,000 453 18,675 83.1 13,639 60.7 12,644 56.3 50.0 1270 6
48 1220 1.06 0.81 1,441 654 18,675 83.1 13,639 60.7 12,644 56.3 50.0 1270 7
Heavy-Duty 18 460 0.34 0.26 869 394 18,675 83.1 13,639 60.7 12,644 56.3 50.0 1270 3
Plate Lip 24 610 0.50 0.38 938 425 18,675 83.1 13,639 60.7 12,644 56.3 50.0 1270 4
30 760 0.64 0.49 1,122 509 18,675 83.1 13,639 60.7 12,644 56.3 50.0 1270 4
36 915 0.78 0.60 1,298 589 18,675 83.1 13,639 60.7 12,644 56.3 50.0 1270 5
Ditching 48 1220 0.67 0.51 841 381 25,230 112.2 14,948 66.5 13,722 61.0 37.0 940 0
60 1525 0.90 0.69 937 425 25,230 112.2 14,948 66.5 13,722 61.0 37.0 940 0
*All capacities are SAE heaped ratings.
