16
EN INITIAL SETTINGS (cont.)
Turn on the VCR and the TV, and select the VCR
channel 3 or 4 (or AV mode) on the TV.
2
Access Main Menu screen on VCR
Press MENU.
3
Access Initial Set screen
Press SHUTTLE PLUS %fi to move the highlight
bar (arrow) to “INITIAL SET”, then press OK or
SHUTTLE PLUS
#.
4
Access Cable Box Set screen
Press SHUTTLE PLUS
%fi to move the
highlight bar (arrow) to
“CABLE BOX SET”,
then press OK or
SHUTTLE PLUS
#.
5
Select cable box output channel
Your selection depends
on how your cable box
is connected to your
VCR.
● If your cable box is
connected to your
VCR’s ANTENNA IN
terminal on the rear
Press SHUTTLE PLUS
%fi on the Remote until
the channel number representing the cable
box’s output (CH2 – CH9) appears on the
screen.
● If your cable box is connected to your VCR’s
AUDIO/VIDEO IN connectors on the front panel
Press SHUTTLE PLUS
%fi on the Remote until
“ON F-1 (FRONT)” appears on the screen.
● If your cable box is connected to your VCR’s
AUDIO/VIDEO IN connectors on the rear panel
Press SHUTTLE PLUS
%fi on the Remote until
“ON L-1 (REAR)” appears on the screen.
● If you do not use a cable box
Press SHUTTLE PLUS %fi on the Remote until
“OFF” appears on the screen.
INITIAL SET
CLOCK SET
LANGUAGE
ENGLISH
GUIDE CHANNEL SET
=CABLE BOX SET
DBS RECEIVER SET
SELECT WITH ( 5,∞) AND (OK)
PRESS (MENU) TO END
CABLE BOX SET
OFF
PRESS ( 5,∞), THEN (OK)
PRESS (MENU) TO END
1 2 3
4 5 6
7 8 9
0
2
4
1
3
2
3 4 6 7
3 – 5
7
Setting cable box output
channel & brand
After installation, set the cable box output’s channel and
its brand correctly; otherwise, the Controller cannot
work correctly.
1
Turn on cable box
Select a channel other than channel 9 on your
cable box.
