JVC GET0735-001A - Manual (Page 13)

13 ENGLISH
Storing your own sound mode
You can store your own adjustments in
memory.
1
2
] ]
[Hold]
3
Adjust the sound elements (see table
below) of the selected tone.
4 Repeat steps 2 and 3 to adjust other
tones.
The adjustments made is automatically
stored and changed to “USER.”
Menu operations
1
If no operation is done
for about 60 seconds, the
operation will be canceled.
2 3 Repeat step 2 if necessary.
• To return to the previous
menu, press BACK.
• To exit from the menu, press
MENU.
[Hold]
Continued...
Menu item Selectable setting, [Initial: Underlined]
DEMO For settings, see page 4.
CLOCK
COLOR
BUTTON ZONE 29 preset colors / USER / COLORFLOW 01/02/03 : Selects your preferred color
for buttons illumination (except for DISP / BRIGHTNESS /
0) and display color
separately.
• If is selected, the button and display illumination will change to the
current/selected color.• Initial color : BUTTON ZONE [ 06 ], DISP ZONE [ 01 ], ALL ZONE [ 06 ]DISP ZONEALL ZONEAll zoneDisplay zoneButton zoneFrequency / Level / Q [Initial: Underlined ]BASS60 / 80 / 100 / 200 Hz–06 to +06 [ 00 ]Q1.0 / 1.25 / 1.5 / 2.0MIDDLE0.5 / 1.0 / 1.5 / 2.5 kHz–06 to +06 [ 00 ]Q0.75 / 1.0 / 1.25TREBLE10.0 / 12.5 / 15.0 / 17.5 kHz–06 to +06 [ 00 ]Q FIXEN02-19_KD-R628[J]f.indd 13EN02-19_KD-R628[J]f.indd 1311/2/10 10:36:03 AM11/2/10 10:36:03 AM
• Initial color : BUTTON ZONE [ 06 ], DISP ZONE [ 01 ], ALL ZONE [ 06 ]
DISP ZONE
ALL ZONE
All zone
Display zone
Button zone
Frequency / Level / Q [Initial: Underlined ]
BASS 60 / 80 / 100 / 200 Hz –06 to +06 [ 00 ] Q1.0 / 1.25 / 1.5 / 2.0
MIDDLE 0.5 / 1.0 / 1.5 / 2.5 kHz –06 to +06 [ 00 ] Q0.75 / 1.0 / 1.25
TREBLE 10.0 / 12.5 / 15.0 / 17.5 kHz –06 to +06 [ 00 ] Q FIX
EN02-19_KD-R628[J]f.indd 13 EN02-19_KD-R628[J]f.indd 13 11/2/10 10:36:03 AM 11/2/10 10:36:03 AM
