Toolbox Installation Instructions 11
Installation
INSTALLATION INSTRUCTIONS (CONTINUED):
Optional Side Mount Toolbox - Divider installation instructions:
1. Peel the backing off of each piece of CO-Tape (B) and then place the CO-Tape
pieces (B) onto the back of each TB-Channel (C) as shown below.
Note: There are only three TB-Dividers (D) supplied with the side mount toolbox (A).
2. Now determine exactly where you would like to place the toolbox dividers. Mark out
the locations for each TB-Channel (C) in the side mount toolbox (A) and then stick
the TB-Channels (C) onto these locations.
Note: You should place a TB-Channel (C) at each marked location at both the front and
back of the side mount toolbox (A) to allow the TB-Divider (D) to slide into place.
3. Now slide a TB-Divider (D) into the TB-Channel (C) at each location.
B
Front
Rear
C
A
C
A
D
