Stealthbox SB-VW-NB/10W3 Stealthbox 2000 Sheet SKU#011143 Revision 03/15/01
Supplied Materials:
1 - 3/8” x 1 1/2” Bolt
1 - 3/8” Fender Washer
1 - 3/8” Lock Washer
1 - Sheet Wax Square
1 - Floor w/Foam Stand-Offs
1 - Rear Trim Panel
1 - 1/2” Fender Washer (On Box)
1 - 1/2” Wing Nut (On Box)
Picture #7
Picture #9
STEP 11: Install the supplied rear trim panel with the
factory connectors that were used to secure the rear
fl ap of the factory fl oor/carpet that was removed in
Step #1. All pieces are shown in Picture #7.
Picture #9 shows the completed installation.
Picture #8
10369 N. Commerce Parkway
Miramar, FL 33025
www.jlaudio.com
Specifi cations:
Enclosure Type: Acoustic Suspension (Sealed)
Driver Type: 10W3-D2
Cont. Power Handling: 250 Watts
Nominal Impedance: Dual 2
Ω
(Wired to 4
Ω
Mono)
