JVC XA-F107A User Manual
Page 87
43
ADVANCED FEATURES
3.
Remove a screw on the side of the LINE IN jack with a screwdriver.
4.
Remove the top half of the casing by lifting it up.
5.
Remove the three screws shown in the illustration below.
6.
Hold the part shown in the illustration below and turn the circuit board over.
LVT1542-002A[US]_Eng.book Page 43 Thursday, February 2, 2006 4:46 PM
