SYSTEM CONNECTIONS (cont.)
Connection To
A Satellite
Receiver
The AV2 IN connector on the rear panel of your recorder allows
simple connection to a satellite receiver.
NOTES:
●
When connecting your recorder to a TV equipped with 21-pin AV input connectors (SCART), follow the illustration above using the
cables shown in gray.
●
For details, check your satellite receiver’s instruction manual.
Satellite Receiver
Unit
Satellite Cable
Outdoor Unit
Aerial
TV Aerial cable
ANT. IN
RF OUT
Mains outlet
Back of Recorder
