JVC TM-H1375SU - Manual (Page 2)

Model TM-H1375SU
Type Color Video Monitor
Color System NTSC/PAL
Scanning Frequency H: 15.75kHz (NTSC)/15.625kHz (PAL)
V: 50/60Hz
CRT 13 Љ (diagonally measured)
Dot pitch 0.28mm
Horizontal Resolution More than 750 TV lines (Y/C input mode)
Power Requirement 120V AC, 50/60Hz
Power Consumption 1.2A (tentative)
Colour Temperature 6500˚/9300˚ selectable
Input Terminals
Input A Composite 1 line, BNC connector ן2,
1.0V(p-p), 75 ohms, negative sync,
auto-termination, bridged output possible
Input B Composite 1 line, BNC connector ן2,
1.0V(p-p), 75 ohms, negative sync,
auto-termination, bridged output possible
Y/C 1 line, mini-DIN 4-pin ן2
Priority Y: 1.0V(p-p), 75 ohms, negative sync
C: 0.286V(p-p), 75 ohms (NTSC Burst)
0.3V(p-p), 75 ohms (PAL Burst)
auto-termination, bridged output possible
Audio Terminals RCA pin ן4 for input A and B,
0.5V(rms), high-impedance,
bridged output possible
Remote INPUT A/B 1 line, RCA pin ן1
Remote ASPECT 1 line, RCA pin ן1
Audio Speaker 3- 3 /
16
؆ (8cm) roundן1,
1W output (monaural)
Dimensions (W ןHןD) 13- 5 /
8
ן12- 1 /
4
ן14- 13 /
16
inches
346 ן310ן375mm
Weight 30 lbs. (13.2kg)
DISTRIBUTED BY
Design and specifications subject to change without notice.
®
JVC PROFESSIONAL PRODUCTS COMPANY
DIVISION OF JVC AMERICAS CORP.
1700 Valley Road, Wayne, N.J. 07470
TEL: (973) 315-5000, (800) 582-5825
FAX: (973) 315-5030
E-mail: [email protected]
JVC CANADA INC.
21 Finchdene Square, Scarborough,Ontario M1X 1A7
TEL: (416) 293-1311 FAX: (416) 293-8208
Internet Web Site http://www.jvcpro.com/
Specifications Features
ICK-0234
■ The Hachioji Plant of Victor Company of Japan, Ltd., has received ISO14001 Certification
under the global standard for environmental management.
Ⅲ A/B two composite video input channels with bridged
connection capability
Ⅲ S-VHS (4-pin) input common to B channel with bridged
connection capability
Ⅲ On-screen menu for precise picture adjustment
Ⅲ PHASE/CHROMA/BRIGHT/CONTRAST direct access
adjustment
Ⅲ Wired remote control functions for A/B input channel
selection and for 4:3/16:9 aspect ratio changeover
